Antifreeze coolants are often misunderstood. They come in many different colours, they can often be overlooked as part of a regular service, and most importantly, not everyone is sure what they actually do. Well, these coloured functional fluids are very important, and it is vital to use the correct antifreeze coolant to help ensure that car engine works at maximum operational efficiency. It is commonly known, given the product category name, that antifreeze coolants help protect the engine against freezing in the winter, but it is often the misconception that this is the sole benefit. There are a lot more features and benefits to these functional fluids.
Choosing and using the correct antifreeze coolants can be confusing. To help the automotive sector get a better understanding of what functions antifreeze coolants perform, plus the importance of choosing and using products with the correct specification, Morris Lubricants’ Technology Manager, Adrian Hill, has developed a list of his top ten tips for antifreeze coolants.
ANTIFREEZE COOLANTS ARE NOT JUST WINTER PRODUCTS
Antifreeze coolants are designed to protect engines and keep them working, regardless of the ambient temperature. Therefore, they are products that are used all-year-round. Antifreeze coolants are not just used for the winter to protect against freezing, they also help keep the engine from overheating during the summer months, when the ambient temperature is hot or when a car is running yet standing still in heavy traffic for long periods of time.
WHY NOT JUST USE WATER TO COOL THE ENGINE?
Water is the best cooling medium available and very effective at removing heat from around the engine’s combustion chamber and hence keeping the engine at an optimised running temperature. However, if the ambient temperature drops below 0ºC, water will freeze and ice crystals will form. Ice is less dense than water and takes up more volume in the engine cooling system. With nowhere for this ice to go, it will force its way out, damaging the engine and coolant system. Conversely, water boils at 100ºC, and since the combustion process in a car engine can reach several thousand degrees, even in a pressurised system, the water will be lost as steam. This is where antifreeze coolants and their carefully balanced formulations take over from just pure water alone. To combat these physical challenges, monoethylene glycol (MEG) is used as the base for antifreeze coolants and for good reason. Monoethylene glycol disrupts the formation of ice crystals and will protect down to -40ºC (by using a 50% mixture with distilled, deionised or demineralised water), preventing damage. When the engine reaches operating temperature, monethylene glycol (within the pressurised cooling system) increases the boiling point and temperatures can reach 110ºC.
WHAT OTHER FUNCTIONS DO ANTIFREEZE COOLANTS PERFORM?
To protect the different metals and alloys used in the construction of the engine, the antifreeze coolant must also contain rust and corrosion inhibitors. Rusting and corrosion can happen due to the presence of oxygen or other contaminants, but the inhibitors either form a chemical barrier or neutralise the rusting and corrosive reactions. Rust and corrosion can also be prevented if the antifreeze coolant mixture has a slightly alkaline pH, usually around 8.5. This will also control the degradation of rubber and plastic components such as hoses, seals, gaskets, etc. Therefore, antifreeze coolants are enhanced with chemical additives such as pH buffers to help to control this rusting, corrosion and degradation.
As the antifreeze coolant is pumped and churned around the coolant system, air can become entrained, and so the product must also have antifoaming properties. Foam is basically air bubbles, and air is not very good at removing heat. This will not only lead to overheating, but also cavitation, that will impede antifreeze coolant flow, making matters even worse. Antifoam chemical additives ‘break’ the foam and release the air.
WHY ARE THERE SO MANY ANTIFREEZE COOLANTS AVAILABLE IN THE MARKET?
Over the past 15 years, the development of engine technology has been very fast-paced, and many different engine designs have emerged. On the roads today, there are so many different engine types, such as petrol, diesel, and hybrid, each with their own ways of developing power to the wheels. This complexity is a result of Original Equipment Manufacturers (OEMs) taking different approaches to help improve efficiency, reduce fuel consumption, improve reliability and lower emissions. To deliver on these new engine platforms, the OEMs are using innovative materials, alloys, etc, in the manufacturing of these new designs.
The antifreeze coolants, therefore, must be manufactured to perform in engines made from these differing materials and not corrode the engine, its components or parts of the coolant system, such as the water pump, hoses, radiator, etc.
WHAT DOES THIS MEAN?
This means that there is not one antifreeze coolant that will suit all types of engine design. Antifreeze coolant formulations are developed and tailored to meet the strict demands of the OEMs, of whom there are many.
The market consists of traditional 2-year antifreeze coolants, with ‘old school’ fast-acting chemistry and 5-year coolants that manage protection in a more controlled way. But as the metallurgies used in engine designs continue to develop, alongside changing duty cycles, antifreeze coolant technology has needed to evolve in parallel, to help maximise engine protection as well as prevent freezing and overheating.
This delicate balance of chemistry is essential to protect engine platforms and ensure maximised operating efficiencies. The OEMs drive the development of these formulations, targeting which chemical additives are needed and hence buying and using the correct antifreeze coolant is essential.
ADRIAN’S TOP TEN TIPS
1. DON'T SELECT BASED ON COLOUR:
Colour is purely cosmetic and does not contribute to performance.
2. NEVER MIX ANTIFREEZE COOLANTS WITH DIFFERENT SPECIFICATIONS:
They may react and cause system issues.
3. NEVER MIX WITH TAP WATER.
Hard water salts can block the system. Always use distilled, deionised or demineralised water.
4. FOLLOW THE SERVICE GUIDELINES SET BY THE OEM AND CHANGE ACCORDINGLY:
2 years or 5 years, depending on the antifreeze coolant specifications.
5. IF THE VEHICLE IS NEW TO YOU WITHOUT ANY SERVICE HISTORY, CHANGE THE COOLANT AS AN INSURANCE POLICY.
6. ROUTINELY CHECK THE COOLANT SYSTEM, LOOKING FOR LEAKS, ETC.
This will ensure maximum system efficiency.
7. IF YOU ARE UNSURE OF THE OEM SPECIFICATION REQUIRED, SEEK TECHNICAL ADVICE.
The correct specification will ensure maximum protection. The Morris Lubricants online tool, WhatOil, is an ideal place to find the correct antifreeze coolant needed.
8. CHECK AND MAINTAIN THE COOLANT LEVEL ALL-YEAR-ROUND.
The coolant is essential for both hot weather as well as cold.
9. USE THE CORRECT MIX RATIO WITH DISTILLED, DEIONISED OR DEMINERALISED WATER (50:50, FOR EXAMPLE)
This will ensure high and low temperature protection is achieved.
10. CORRECT COOLANT SELECTION CONTRIBUTES TO OPTIMISED ENGINE OPERATION AND EFFICIENCY.
This is only a very short overview of this vitally important functional fluid. If you want to find out more about the importance of selecting and using the correct antifreeze coolant, head over to the Morris Lubricants' YouTube channel now.
Here you will find a series of short and longer videos where Adrian dives deeper into the topic of antifreeze coolants and gives some valuable industry insights on how these products are formulated and why.
The Morris Lubricants’ range has you covered
Morris Lubricants has developed the Ultralife range of antifreeze coolants to cover a broad range of car engines and across many different manufacturers. The Ultralife range is ideal for fleet managers, dealerships and mechanics that are responsible for a variety of different vehicle technologies, OEM brands and vehicle models.
Confused? Is there too much choice? Are you not sure what to use? There is no need to worry, you can seek help from Morris Lubricants and use the company’s WhatOil online oil, lubricant and functional fluid finder. Searches are easy, and often, by just entering a car registration number, you can see what antifreeze coolants are recommended for that vehicle.
If you are still not sure or would like additional advice on what oils are needed, you can also contact Morris Lubricants’ dedicated Technical Services Department on 01743 237541 or email them on technicalhelpdesk@morris-lubricants.co.uk, where a team of experts are on hand to answer your questions.
Further information about Morris Lubricants’ range of products can be found on morrislubricants.co.uk. You can also speak to our sales team on 01743 232200.
